EU prop 20 kN
- Hot-dip galvanised
- EN 1065 compliant
- Head plate 120 x 120 x 8 mm or 140 x 140 x 8 mm, hole ø 41 mm
- Compatible with all common heads
- Fixing peg diameters 14 mm & 15 mm
- Smooth-action external thread
- Long lifespan
- Drop-out stop and anti-trap guard
- Hole numbering
- Loadable up to 45.0 kN (see data sheet)
Sizes and extension lengths:
BD25 - adjustment range: 1,51 - 2,50 m
BD30 - adjustment range: 1,80 - 3,00 m
CD35 - adjustment range: 1,98 - 3,50 m
CD40 - adjustment range: 2,25 - 4,00 m
CD45 - adjustment range: 2,50 - 4,50 m
CD55 - adjustment range: 3,10 - 5,50 m
EU prop 30 kN
- Hot-dip galvanised
- EN 1065 compliant
- Head plate 120 x 120 x 8 mm or 140 x 140 x 8 mm, hole ø 41 mm
- Compatible with all common heads
- Fixing peg diameter 16 mm
- Smooth-action external thread
- Long lifespan
- Drop-out stop and anti-trap guard
- Hole numbering (not E40)
- Loadable up to 42.0 kN (see data sheet)
Sizes and extension lengths:
CE30 - adjustment range: 1,80 - 3,00 m
CE35 - adjustment range: 2,00 - 3,50 m
CE40 - adjustment range: 2,25 - 4,00 m
Floor prop industry class B
- EN 1065 compliant
- Head plate 120 x 120 x 6 mm, holeø 41 mm
- Compatible with all common heads
- Slip-ring for easy adjustment
- Fixing peg diameter 14 mm
- Greased, smooth-running, covered thread
- Long lifespan: dip-painted, galvanised thread sleeve and peg
- Drop-out stop and anti-trap guard
- Loadable up to 30 kN (see data sheet)
Sizes and extension lengths:
B30 - adjustment range: 1,84 - 3,00 m
B35 - adjustment range: 2,05 - 3,50 m
B40 - adjustment range: 2,35 - 4,00 m
